Installers manual 10.03.02-R03 (201058) EN SDA-04 (SW 5.xx) - SDA-04DCB2 (SW 22.00) Page 26 of 55
Parameter 74 : (0) Relay output 3 (multifunction relay)
0 = Relay is disabled
1..11 = Please refer to legend 7.3.4.
When parameter 74 is set to 5 or 6, the power feed to the external
(NON EN16005) sensors must be switched via this contact. This will allow the
controller to switch the sensors on and off during a test cycle.
When the controller is set in accordance to the EN16005:
Relay 3 will be automatically configured as a monitoring relay for safety
devices. No other setting is possible.
Parameter 75 : (0) Relay 3 configuration (N.O. or N.C.)
0 = Relay is set as normally open (N.O.)
1 = Relay is set as normally closed (N.C.)
Parameter 76 : (0) Motor Lock Activation
Note: motor lock can only be activated when parameter 70= 0 (mandatory)
Note: this parameter will be active after 1 door cycle
0 = In the event that the door has closed in a locked state (input 1 and/or 2 are active),
relay 1 will be activated. Motor lock will stay idle.
1 = In the event that the door has closed in a locked state (input 1 and/or 2 are active),
relay 1 will be activated along with the motor lock.
Warning:
Note: motor lock is not a means to burglary protection.
Parameter 77 : (0) Motor Lock without external activation
Note: can only be used when parameter 70= 0 and 76=1 (mandatory)
Note: this parameter will be active after 1 door cycle
0 = Motor Lock is only active on contact closure of inputs 1 and/or 2
1 = Motor Lock is always active and does not need activation based on an external
contact. Pulling on the door will activate the motor lock
Parameter 78 : (0) Motor Lock in the event of a fault
0 = In the event of a fault, the lock relay and/or the motor interlock will be
overridden by the controller
1 = In the event of a fault, the lock relay and/or the motor interlock will be
held in their current position
Parameter 79 : Reserved for future applications
