4.6.1 Dismantling the Wire Drive Assembly
Referring to DIAG 8 and Sub Assembly’s A-C:
Remove the Rear Wire Guide (E2).
Remove the Gas Head, as in Section 4.4.
Unscrew the Bear Housing (E1) with a Peg Spanner / C Spanner and withdraw the
Wormshaft.
Separate the Bearing (C4) from the Bearing Housing (C1), if necessary using an
appropriate tool.
Unscrew the Cap Retaining Screw (C2) from the end of the Wormshaft and remove the
Bearing Cap (C3), Ball Bearing (C4) and Bevel Gear (C5).
Examine all parts for wear.
Undo the 2 Roller Feed Nuts (A1) and remove the Wire Rollers (A2).
Remove the Dust Excluders (A3), Feed Roll Cover (A4) and Feed Roll Gasket (A5).
Unscrew the Cover Screw (B1) found on the right hand side of the pistol.
Screw out the Slotted Head Screw (B2), retain the Threaded Spring Support (B4), Plain
Spring Support (B3) and Springs (B5).
Slacken the Lock Screw (E3) and withdraw the Wire Feed Lever (E4).
Remove the Socket Set Screw (E9).
Remove the Spacer (E7) using one of the Gas Head Fixing Screws as an extractor.
Remove the Socket Set Screw (E8).
Extract the Yoke Support (E5) and Bearing (E6) from the Pistol Body.
Taking the Yoke Assembly (B6), unscrew the Socket Set Screws (B7) securing each
Roller Gear (B8), and slide the Roller Shafts (B9) from the Yoke Assembly (B6).
WHEN & WHY?
The Wire Drive Assembly should only be dismantled when it is absolutely necessary.
For example:
There is excessive play in Wire Rollers.
The Wire Rollers cannot be opened.
The Wire Feed Lever spins through 360°
