Variations Tables:
Nozzle Shell Variations
Screwed Insert Variations
1015
1/8” Nozzle
1288I
Scrwd Insrt, 3/16 Stop/Start
1281
Nozzle Fast 3/16” Propane
1289I
Screwed Insert, 4mm Propane
3804
2.0mm Nozzle - Fine Spray
1290I
Screwed Insert, 1/8 Propane/Acetylene
3803S
1.5mm Nozzle - Fine Spray (Jm)
1291I
Screwed Insert, 3.0mm Propane/Acetylene
3803(1.6)
1.6mm Nozzle - Fine Spray
1292I
Screwed Insert, 2.3mm Propane/Acetylene
1295/SHELL
Nozzle Shell <1.6 Fine Spray
1293I
Screwed Insert, 2.0mm Propane/Acetylene
1293/SHELL
Nozzle Shell 2.3mm & 2.0mm
1295I
Screwed Insert, 1.5mm Propane/Acetylene
1290/SHELL
Nozzle Shell 1/8” & 3mm
1288/SHELL
Nozzle Shell For 3/16” & 4mm
1297I
Screwed Insert,1.0 Wire Propane
Air Nipple Variations
Mixing Block Variations
1018
2.00mm Air Nipple
1010
Mixing Block (Propane)
1020
1/8” Air Nipple
1055
Mixing Block (Fine Spray)
1302
Air Nipple 3/16”
1056
Mixing Block (2.0mm Fine Spray)
3829
Air Nipple - Deflector
1270
Mixing Block – Propane
3823
Air Nipple - Fine Spray
1271
Mixing Block Fast Propane
Front Wire Guide Variations
4509F
3/16” Front Wire Guide, Fast
1429/20
Front Wire Guide (2.0mm)
1429/3/16”
Front Wire Guide (3/16”)
1429/16
Front Wire Guide (1.6mm)
1429/40
Front Wire Guide (4.0mm)
1429/15
Front Wire Guide (1.5mm)
1429
1/8” Front Wire Guide
1429/10
Front Wire Guide (1mm)
1429(3)
3mm Front Wire Guide
4539
2.0mm Front Wire Guide
1429/23
Front Wire Guide (2.3mm)
Spreader Ring Variations
1252
3/16” Spreader Ring
1255
3/16” Spreader Ring (Mk73) Fast
The tables that follow list the numbers for the parts of the Nozzle Assembly that are dependent upon
the wire size and pistol variant used. Refer to the Nozzle Selection Chart – Section 8.2
