15
95-2009 DASH DISASSEMBLY
1
Open passenger door and remove panel on end of dash.
Disconnect the negative battery terminal to prevent an accidental short circuit.
3
Open drivers door and remove fuse panel on end of dash.
2
Remove (1) Phillips screw from each side exposed.
4
Remove (3) screws from top of glove box liner.
5
Remove (2) screws from the top-left corner of the glove box cavity.
6
Remove (1) Phillips screw from the defroster duct.
7
Remove the ductwork and (1) Phillips screw exposed.
8
Remove the dash pad and (3) Phillips screws exposed at the top of the radio trim
bezel.
9
CHEVROLET • CAVALIER 2000-2005
Continue to kit assembly.
