95-2009 DASH DISASSEMBLY
BUICK • RENDEZVOUS 2002-2007
1
Remove liners from cup holders and storage pocket next to cup holders,
then remove screws. Unsnap and remove panel.
Disconnect the negative battery
terminal to prevent an accidental short circuit.
3
Open center console and remove 2 screws at front of console opening.
2
Remove (2) screws from bottom of radio/climate control bezel, unclip and remove.
4
Remove (3) 9/32" hex head screws to remove radio.
5
Continue to kit assembly.
To Next Page
