29
95-2009 DASH DISASSEMBLY
HONDA • PASSPORT 1998-2002
ISUZU • AMIGO 1998-2000 / RODEO 1998-2004
RODEO SPORT 2001-2003
1
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
Remove the ashtray and (1) Phillips
screw exposed in the ashtray cavity.
Unclip and remove the trim panel
surrounding the factory radio.
Remove (4) Phillips screws securing
the factory radio and disconnect the
wiring.
2
C
ontinue to kit assembly.
To Next Page
