95-2009 DASH DISASSEMBLY
BUICK • CENTURY 1997-2005 / REGAL 1995-2004
3
1
Unsnap the top edge of the knee
bolster panel.
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
3
Remove the plastic trim piece to the
left of the glove box and (1) Phillips
screw exposed.
2
Remove (1) Phillips screw from the
panel.
4
Remove the ashtray cluster and (2)
Phillips screws from each side.
5
Unclip the entire dash trim bezel and
remove.
6
Open doors and unsnap end caps
from each side of dash.
7
Unsnap and remove radio/instrument
cluster panel.
8
Remove (3) screws in order to remove
radio.
9
Continue to kit assembly.
