39
95-2009 DASH DISASSEMBLY
PONTIAC • AZTEC 2001-2005
1
Remove (1) Phillips screw exposed
inside bottom cup holder.
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
3
Pull out cup holder inserts.
2
Unsnap and remove shifter trim with
cup holders.
4
Remove (2) #15 torx at bottom of
radio/climate bezel.
5
Continue to kit assembly.
To Next Page
