24
95-2009 DASH DISASSEMBLY
1
Remove the ashtray and (1) screw
exposed.
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
3
Remove the cigarette lighter and
climate control knobs.
2
Pull out on the climate control cluster
and remove (2) screws exposed.
4
Unclip the radio trim bezel.
5
Remove (4) screws from the factory
head unit, slide the unit out and dis-
connect the wiring.
6
CHEVROLET • TRACKER 1992-2004
SUZUKI • SIDEKICK 1992-1998 / VITARA 1999-2005
GRAND VITARA 1999-2002
XL-7 2001-2002
Continue to kit assembly.
