22
95-2009 DASH DISASSEMBLY
1
Remove (2) 9/32" screws from the
knee panel and unclip the panel.
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
3
Unclip the trim panel above the ped-
als. (It is NOT necessary to remove
the panel it may be left hanging).
2
Unsnap the driver's side fuse panel
cover and remove (1) 9/32" screw.
4
Open the glove box and remove (1)
9/32" screw from the upper left
corner.
5
Remove (3) 9/32" screws securing
the factory radio and disconnect the
wiring.
6
CHEVROLET • MONTE CARLO 2000-2005
Continue to kit assembly.
