28
95-2009 DASH DISASSEMBLY
GMC • ENVOY 2002-2009 / ISUZU ASCENDER 2003-2009
OLDSMOBILE • BRAVADA 1998-2004
BUICK • RAINIER 2004-2007
2. Remove (4) Phillips screws, (2) from left and (2) from right of carpeted panel.
3. Slide carpeted panel down and backwards to reveal (2) Phillips screws and remove.
4. Unsnap radio bezel and unplug cigarette lighter and accessories.
5. Remove (3) screws and remove radio.
Continue to kit assembly.
1
Disconnect the negative battery terminal to prevent an accidental short circuit.
To Next Page
