47
95-2009 TAB INSTRUCTIONS
ISUZU-PONTIAC/TOYOTA/
CADILLAC-ELDORADO/SEVILLE
ISUZU Amigo/Rodeo/Rodeo Sport.
Cut tabs highlighted.
(Figure D)
4
TOYOTA Matrix/PONTIAC Vibe.
Cut tabs highlighted.
(Figure E)
Cut (4) tabs
highlighted
on double DIN
trim plate. (Figure H)
5
CADILLAC Eldorado/Seville.
Cut tabs highlighted on double DIN
brackets.
(Figure F)
Cut (1) tab
highlighted on top left corner
of double DIN trim plate.
(Figure G)
6
Continue to final assembly.
Continued from page 46.
*Note: Refer also to the instructions included with the aftermarket radio.
D
E
F
G
H
