Metra Electronics 95-2009 - Kit Assembly and Mounting Guide

48
95-2009 KIT ASSEMBLY
TOP FACTORY BRACKET
BOTTOM FACTORY BRACKET
1
Using carriage bolts and Keps nuts supplied, mount the factory brackets to the
double DIN trim plate/double DIN bracket assembly, keeping in mind which
bracket is top and which one is bottom.
CADILLAC • FLEETWOOD
FLEETWOOD BROUGHAM
1990-1996
KIT ASSEMBLY WITH FACTORY BRACKETS
