32
95-2009 DASH DISASSEMBLY
OLDSMOBILE • ACHIEVA 1996-
1
Remove (10) torx-head screws from
the glove box location.
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
3
Open the glove box, press inward on
the walls of the glove box liner and
remove the liner.
2
Remove (2) 9/32" hex-head screws
under the steering column.
4
Unclip the dash trim bezel.
5
Remove the screws securing the
factory head unit and disconnect the
wiring.
6
Continue to kit assembly.
To Next Page
