95-2009 DASH DISASSEMBLY
PONTIAC • BONNEVILLE 2000-2005
1
Unclip the ignition trim and remove.
Disconnect the negative battery terminal to prevent an accidental short circuit.
3
Remove (2) Phillips screws from the instrument cluster.
2
Unclip the climate control/radio trim bezel and remove.
4
Depress the spring clips on each side of the factory head unit and remove.
5
Continue to kit assembly.
