27
95-2009 DASH DISASSEMBLY
1
Disconnect the negative battery terminal to prevent an accidental short circuit.
CHEVROLET • VENTURE 2001-2005
OLDSMOBILE • SILHOUETTE 2001-2004
PONTIAC • MONTANA (EXCEPT SV6) 2001-2005
Remove (1) Phillips screw from the cigarette lighter compartment.
3
Remove the ashtray and (1) phillips screw exposed in the ashtray cavity.
2
Remove (2) Phillips screws securing the factory head unit and disconnect the
wiring.
4
Continue to kit assembly.
To Next Page
