1
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
Unclip the bottom edge of the radio
trim panel then lift up and out to
remove. (Figure A)
2
Remove (4) 10MM bolts securing the
factory radio. (Figure B)
3
Continue to kit assembly.
A
B
To Next Page
