45
95-2009 DASH DISASSEMBLY
SUZUKI • ESTEEM 1995-
1
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
Remove the climate control knobs.
2
Remove (1) Phillips screw located
above the radio opening.
3
Unclip the radio trim bezel.
4
Remove (4) screws from the factory
head unit, slide the unit out and dis-
connect the wiring.
5
Continue to kit assembly.
To Next Page
