5 Installation
916 Ti‑Touch
￭￭￭￭￭￭￭￭
21
Balance Cables
Sartorius MP8, MC, LA, Genius,
Cubis
6.2134.060
Shimadzu BX, BW 6.2125.080 + 6.2125.010
Connect the balance as follows:
1
Connect the USB plug of the USB/RS-232 adapter with the USB con-
nector of the Ti‑Touch (Type A).
The USB/RS-232 adapter will be recognized automatically and
entered in the device manager of the Ti‑Touch.
2
Connect the RS-232 interface of the USB/RS-232 adapter with the
RS-232 interface of the balance (see table for cable).
3
Switch on the balance.
4
If necessary, switch on the RS-232 interface of the balance.
5
Configure the RS-232 interface of the USB/RS-232 adapter in the
device manager of the Ti‑Touch .
6
Enter and configure the balance in the device manager of the
Ti‑Touch.
7
Make sure that the parameters of the USB/RS-232 adapter config-
ured in the device manager match those of the balance.
5.6.5 Connecting a PC keyboard
The PC keyboard is used as an aid for text and numerical input.
Connect the PC keyboard as follows:
1
Connect the USB plug of the keyboard with the USB connector of
the Ti‑Touch (Type A).
2
Enter and configure the keyboard in the device manager of the
Ti‑Touch.
