Combustion-IC-System
4 Start-up
All of the Combustion IC system components have to be completely
installed before putting the 920 Absorber Module into operation; this
means:
￭ The Combustion Module including ABD and optional sampler (MMS
5000) and, if necessary, the LPG/GSS Module is installed according to
the specifications in the Combustion IC operating instructions from
Analytik Jena/TEI.
￭ The Combustion Oven (TEI) including, if applicable, Liquid Autosampler
CIC, Solid Autosampler CIC and/oder GLS Autosampler CIC from Trace
Elemental Instruments is installed according to the operating instruc-
tions.
￭ The 920 Absorber Module is installed according to the specifications in
the manual for the 920 Absorber Module and is connected to the
Combustion Module (AJ) / Combustion Oven (TEI).
￭ The 930 Compact IC Flex (2.930.2560) is installed according to the
specifications in the manual for the ion chromatograph and is con-
nected to the 920 Absorber Module.
￭ The ion chromatograph is connected to a computer where the
MagIC Net software and TEIS are installed. TEIS is only necessary for
the Combustion Oven (TEI).
Putting the Combustion IC system (AJ) into operation
1
Starting the software
￭ Switch on the computer and start the software MagIC Net.
￭ Enter user name and password.
The software starts and shows the Workplace program part.
2
Switching on the instruments
￭ Switch on the Combustion Module (AJ): the Combustion Module
(AJ) and the MMS 5000 sampler (AJ) or the LPG/GSS Module (AJ),
if present.
￭ Switch on the Combustion-IC-System.
￭ Switch on the ion chromatograph.
MagIC Net detects all of the instruments and asks if they are to be
saved to the device table.
￭ Confirm all of the prompts with [Yes].
