Equipment Code : ...> F7
Sequence Name : ...> F6
Class: CL1 ,0 leads in 0 modules.......> F5
MORE MEMORY SETUP START
F1 F2 F3 F4
3. MORE (F1). When MORE (F1) is pressed, the following dis-
play will appear:
Test according to : IEC60601.1 ......> F7
Test Type : Rapid ...........> F6
Test Mode : Automatic .......> F5
GO BACK START
F1 F2 F3 F4
This window offers the following functions:
• Press Test according to (F7) to select either IEC 601.1, IEC
601.2.4, IEC 1010-1, UL 2601.1, IEC61010, AS 3200.1,
HEI 95, ANSI/AAMI, VDE 751 or VDE 751-DEF Standard.
• Press Test Type (F6) to select either Rapid or Normal test
type.
• Press Test Mode (F5) to choose between Automatic and
Manual test.
• Press GO BACK (F2) to return to the previous display.
• Press START (F4) to start the test.
4. MEMORY (F2)
QA-90’s memory is divided into two parts: tests and sequences. If
you have several equivalent instruments to test, you can define one
test sequence for all the instruments and store it as a sequence.
You use this sequence to test all the instruments and store each of
the test results with the instrument’s respective equipment code.
The functions in the MEMORY menus enable you to store, re-
trieve, transfer, print and delete test results and sequences from the
memory. The four main memory displays are as follows.
