Page #25 background image
3-11
Current Consumption ...................> F5
MORE MAIN MENU
F1 F2 F3 F4
4. Press PL on the keypad to obtain the recording window for
Module Code and No of leads.
Module Code : .....> F7
No of leads : .......................> F6
Type : CF.......................> F5
ADD GO BACK PREV. NEXT
F1 F2 F3 F4
5. Select which Module Code to be measured with NEXT (F4) or
Prev. (F3).
6. Press GO BACK (F2).
7. Press START (F1) to start the test.
8. Press STOP (F1) to stop the test.
9. To select a new module, press PL and repeat the same procedure.
3.7 Storing Setup Parame-
ters in Flash Memory
The following parameters can be stored in Flash memory:
Operator
Establishment
Serial Number
Language
Calibration parameters
To store the setup parameters in Flash memory, go to SETUP (F3) in
MAIN MENU.
Equipment Code : ...> F7
Sequence Name : ...> F6
Class: CL1 ,0 leads in 0 modules.......> F5
MORE MEMORY SETUP START
