METRON QA-90 User Manual

3-4
3.4 Menu and Function
Keys
The QA-90 uses displays, function keys and a keypad to provide flex-
ibility and control over operations. The top three lines in the display
are used for messages, status and results. The menu bar is shown at
the bottom of the display. Function keys are numbered from F1 to F7.
A function/menu is selected by pressing that key which is directly be-
low/to the right of the menu unit shown in the display.
3.5 Display Menus and
Messages
1. Startup Screen. The following screens will be displayed in se-
quence for the first 10 seconds after the QA-90 has been switched
on.
METRON QA-90 F7
F6
Boot software version: X.XX F5
F1 F2 F3 F4
METRON QA-90 F7
F6
Version: X.XX Date: DD/MM/YYYY F5
F1 F2 F3 F4
METRON QA-90 Electrical Safety Analyzer F7
TOTAL MEMORY : 114688 F6
TOTAL MEMORY USED : 6884 F5
TOTAL FREE SPACE : 107804
F1 F2 F3 F4
2. Main Menu
