METRON QA-90 User Manual

4-7
F1 F2 F3 F4
MANUAL TEST SETUP F7
Mains Voltage .........................> F6
Current Consumption ...................> F5
MORE MAIN MENU
F1 F2 F3 F4
Protective Earth ......................> F7
Insulation Resistance .................> F6
Earth Leakage Current .................> F5
MORE GO BACK MAIN MENU
F1 F2 F3 F4
Time : Seconds F7
Result : mOhm F6
Limit : mOhm F5
START GO BACK PRINT MAIN MENU
F1 F2 F3 F4
4.5 Current Measurement
Test (Dual Lead)
This test measures leakage current from one instrument to another in-
strument.
1. Press MORE (F1) in MAIN MENU.
