1. Press Equipment Classification (F6) and select classifica-
tion.
2. Press MORE (F1).
3. Press Test according to (F7) and select test standard.
4. Press Test Type (F6) and select either Rapid or Normal.
5. Press Test Mode (F5) and select either Automatic or manual.
6. Press START (F4) to start the test.
Equipment Code : ...> F7
Sequence Name : ...> F6
Class: CL1 ,0 leads in 0 modules.......> F5
MORE MEMORY SETUP START
F1 F2 F3 F4
Test according to : IEC60601.1 ......> F7
Test Type : Rapid ...........> F6
Test Mode : Automatic .......> F5
GO BACK START
F1 F2 F3 F4
4.3 Connecting an In-
strument with Patient
Inputs
This includes IEC Classifications Body (B), Body Float (BF), and
Cardiac Float (CF).
Connect the mains plug of the instrument to be tested to the QA-90’s
terminal on the front panel. Then, connect a calibrated test lead be-
tween the ENCL connector on the front panel of the QA-90 and the
casing of the instrument to be tested. Following that, connect patient
lead between the instrument to be tested and Patient leads on the QA-
90. (See below)
NOTE
Ensure that the mains
switch on the instrument to
be tested is switched
.
To Next Page
