Equipment Code : ...> F7
Sequence Name : ...> F6
Class: CL1 ,0 leads in 0 modules.......> F5
MORE MEMORY SETUP START
F1 F2 F3 F4
c. Scan an improperly formatted instrument bar code. The QA-
90 should beep to indicate this error.
d. Scan a properly formatted instrument bar code. Check to see
that the Equipment Code and Equipment Class are entered
in the display.
e. Follow the procedure in paragraph 3.6 to advance to the dis-
play window containing the Module Code, No. of Leads
and Type.
Module Code : .....> F7
No of leads : .......................> F6
Type : CF.......................> F5
ADD GO BACK PREV. NEXT
F1 F2 F3 F4
f. Scan an improperly formatted patient lead bar code. The
QA-90 should beep to indicate this error.
g. Scan a properly formatted patient lead bar code. Check to
see that the Module Code, No. of Leads and Type are en-
tered in the display.
2. Automatic Test Sequence with Printout. This checks the QA-
90’s sequence testing function. For the printout function a printer
must be connected to the QA-90, and be ON. See chapter 2 for
additional information.
a. Return to the QA-90’s main menu, then press MORE (F1)
twice to arrive at page 3.
Test according to : IEC60601.1 ......> F7
Test Type : Rapid ...........> F6
Test Mode : Manual ..........> F5
GO BACK START
F1 F2 F3 F4
