Operating Instruction X-Type plus
Operating instructions X-Type plus V1-3.docx Page 12 of 45
4. Transportation and packaging
This section provides an overview of the proper transportation of the Synchroprint.
4.1. General Notes with Regard to Transportation and Danger Warnings
4.2. Packaging
The Synchroprint will be packed and delivered in several wooden crates. The crates’ exact number,
weight and dimensions will vary slightly according to each model/type of machine. Contact
customer service for more information about individual orders.
4.3. Unloading of the crates
The Synchroprint is to be unloaded by the customer. A forklift truck with adequate fork length and
lifting capacity (see 4.2 Packaging) will be required.
4.4. Packaging material
After unpacking the machine, the packaging material must be disposed of according to local
regulations.
Upon delivery of the Synchroprint the consignment must be examined for
external damage immediately. In the case of any damages, they must be
documented and reported to Machines Highest Mechatronic GmbH within 24
hours.
Danger of falling objects!
The following instructions must be observed
1. Never stand or walk under hanging loads!
2. Transportation must be carried out by qualified staff observing all safety
instructions.
3. The Synchroprint must only be lifted at the dedicated lifting points.
4. Only the lifting/handling devices and equipment indicated in this document
must be used for the movement of the Synchroprint. Non-compliance may
lead to serious damage of the Synchroprint and result in cancellation of the
warranty.
Danger of mechanical damage!
The Synchroprint must be lifted carefully and only at the dedicated lifting
points at the middle of the base unit. Lifting the Synchroprint at/by any other
point, especially the turntables, may result in serious damage. Be sure to
maintain an adequate and safe distance during lifting.
