Operating Instruction X-Type plus
Operating instructions X-Type plus V1-3.docx Page 17 of 45
The main control panel includes the following features:
The tablet PC is used to control the main operating features of the
Synchroprint. Touching (tapping) the command buttons displayed on
the screen will operate various individual functions of the machine.
You will find a detailed description of all functions in section “9
Control of the Machine”.
Use “Main switch tablet” to switch the tablet on, off or to put it into
idle state. When the unit is on, push shortly to change into idle state.
After a longer push a menu will be displayed where the unit can be
switched off completely. To start the tablet a short push is enough. The
handling is similar to modern Smartphones.
“Control ON/OFF” is used to switch the control power supply which
supplies all control components inclusive the tablet. To switch off the
main power use the main power switch.
EMERGENCY STOP
(push button)
The EMERGENCY STOP push button is part of the safety facility. See
section 7.4 Safety Devices.
Press the Skip-Button when substrate is not applied in a correct way. In
this case the respective print station will not start to work and the
substrate will not be printed. The print process at other stations and
pallets will not be interrupted.
To cancel a safety device shutdown first press the ERROR RESET
PUSH BUTTON and clear error message on tablet afterwards.
In operating mode ADJUST an automatic error resetting can be
activated with the safety level key; this is needed to adjust the machine
in case of certain adjustment procedures. This can be done by
switching the safety level key to position 1, in normal operation the key
must be in position 0. Only properly trained and appropriately qualified
personnel should use this function. The quick stop function of the turn
table is active all the time. Print and flood strokes can also be made at
active error situations, while a turntable index is prevented.
To load the battery of the tablet the power supply must be connected.
To prevent battery from discharging, press “Main switch tablet” shortly
to put tablet into idle mode. If this is not done, the tablet must be
restarted the next day.
7.4. Safety Devices
The safety devices serve as emergency stop facilities to avoid accidents and to guarantee safe
operation of the machine. The Synchroprint has the following safety devices:
