9.6.2. Basic errors (without error message)
The following error reasons are not recognized by the control system and no error message is
displayed:
Error description
Possible reasons
Trouble-shooting
It’s not possible to start
the tablet m-touch pro
Main power switch is
switched off and battery is
empty.
Switch on main power switch!
“Control ON/OFF” is
switched off and battery is
empty.
Switch on “Control ON/OFF”!
Tablet isn’t connected and
battery is empty.
Connect tablet with machine control!
Power supply of machine is
missing and battery is empty.
Reestablish power supply!
Safety level can’t be
adjusted.
Safety key is not connected
to unit control.
Check wiring from unit control to safety
key!
Wrong wiring of safety key
at control panel housing.
Put control panel out of housing and
check wiring of safety key!
Squeegee does not
toggle at squeegee
carriage movement.
Squeegee pressure too low.
Adjust pressure control at print station!
No air pressure at print
station.
Is manual screen lift working? YES:
Pressure existent. No: Upper pressure stop
cock active or tube snapped off.
Valve not actuated.
Check wiring of squeegee valve!
Screen lift does not
work.
No air pressure at screen lift
unit.
Tube snapped off.
Valve not actuated.
Check wiring of screen lift valve!
Unlock screens does
not work.
Wrong low pressure
adjustment.
Check adjustment of pressure regulator.
Valve not actuated.
Check wiring lock/unlock valve!
