Operating Instruction X-Type plus
Operating instructions X-Type plus V1-3.docx Page 14 of 45
5.4. External supply/Connection ports
Connections for compressed air and mains electricity are located on the base unit of the
Synchroprint as standard. Overhead supply connections may be ordered optionally but only at time
of order, to enable supplies to enter the machine from above, through the centre column.
5.4.1. Electrical Connections
The electrical connections must be designed as follows:
Description
Requirement/Value
Supply voltage
1 x 200-240 V
Supply frequency
50/60 Hz ±5 %
Connected load
1.6 kVA + (0.4 kVA x „number of print heads“)
(= “power for indexer main drive” + “power per print head” x
“number of print heads”)
5.4.2. Compressed Air
Description
X-Type plus
4/2
8/6
10/8
12/10
14/12
Max. air consumption (l/min)
130
220
280
340
400
Air pressure (minimum)
7 bar / 100 PSI
Air quality
filtered, dry air supply only
(class 1:4:1 according ISO8573-1:2010)
All flash cure units must be supplied through a separate/independent
connection. Please observe the precise technical data from the flash cure unit
specification sheet.
Risk of electric shock!
Please observe the general safety regulations for electrical connections when
connecting the mains supply to the Synchroprint. Avoid any contact with live
components.
Danger of tripping over!
In case of laying supply lines on the floor, it is necessary to attach step covers.
