MHM Synchroprint X-Type plus - Basicsetup

Operating Instruction X-Type plus
Operating instructions X-Type plus V1-3.docx Page 38 of 45
9.3.4. BasicSetup
Elementary adjustment must be made in „BasicSetup“.
The following buttons are displayed:
Button
Functional description
Defines the direction of rotation.
Switches between single and double index. At double
index two index moves are made between one working
cycle.
Delay time screen lift. Required time to raise or lower
screen. Input in hundredth of a second.
Optional parameter for index speed. Input in percentage
of maximum index speed.
