Indicates the field is applicable to sample runs .
Indicates the field is applicable to blank runs.
Indicates the field is applicable to volume calibration runs.
Legend
No icon indicates the field is applicable to all SOPs.
Field or Button
Description
Absolute density
[scrollselection]
The density computed after excluding from the volume that of
the pores and cavities.
Analysis Type [button]
Select the type of analysis.
Calculate percent sample
volume [checkbox]
Select to have the percent sample volume calculated. See
Zero Depth of a Sample Chamber on pageE - 1.
Run Blank. Enable to run a blank analysis.
Cancel [button]
Discards any changes or cancels the current process.
Chamber [drop-downbox]
Select the chamber size to be used. Entries in this field can be
modified in the Maintenance section.
Chamber + medium mass
[scrollselection]
Mass of the chamber and medium.
Entered consolidation force
[button]
Default. Tap to use the default consolidation force.
Enter. Tap to manually enter the new consolidation force.
Entered conversion factor [but-
ton]
Default. Tap to use the default conversion factor.
Enter. Tap to manually enter the new conversion factor.
Entered zero depth [button]
Default. Tap to use the default zero depth.
Enter. Tap to manually enter the new zero depth.
SOP Fields and Buttons Table
Add a New Procedure
GeoPyc 1365 Operator Manual
136-42800-01 (Rev -) — Dec 2016
4 - 3
