SediGraph III 5120 Service Service Parts
Mar 2010 10-1
10. SERVICE PARTS
PCBs
Part Number Description
300/17700/011 MIC 386 CPU PCB
512/17701/011 Backplane PCB (power distribution)
512/17702/011 I/O & Control PCB
512/17703/011 Cell Stepper & Heater Control PCB (in Analysis module)
512/17704/011 X-Ray & PMT Control PCB
512/17708/011 Fluid Control PCB
512/17709/011 Interconnect PCB
Power
Part Number Description
003/40069/00 Power supply, Hi-Voltage
003/40049/00 24VDC, 350W (Hot=Brown, Neutral = Blue, Ground = Green)
003/40051/00 Quad switcher
003/51191/00 Circuit Breaker 250VAC, 6A (power On)
Accessories & Other Parts
Part Number Description
003/39046/00 Lamp28V, T 1-3/4 Wedge, GI #85
003/51050/00 Switch, Leaf activated, sub mini
003/51149/00 Switch, key-lock
003/51170/00 Magnet, switch (door & top panel)
