2-8 Micron Electronics, Inc.
Micron ClientPro 766Xi/Xe User’s Guide
Installing Add-On Peripherals
The ClientPro 766Xi/Xe accommodates ISA and PCI Local Bus cards. Extra
SDRAM can also be added to the system board. The following describes how
to install the PCI card and SDRAM memory.
PCI Local Bus Card
PCI Local Bus slots accommodate most PCI-approved Local Bus cards. To install
a PCI Local Bus card:
1. Power OFF the computer system.
2. Locate an unused PCI slot on the system board.
3. Insert the card with the bottom edge level. Never insert the card
at an angle.
4. Holding the card at the center of the top edge, gently push straight
in. Do not force the card into place. If it does not fit, take it out
and try again.
5. Make sure the card is fully inserted.
6. Secure the card with a bracket screw.
Accelerated Graphics Port
The ClientPro 766Xi/Xe also comes with an Accelerated Graphics Port (AGP).
This is a high-performance interconnect for graphic-intensive applications,
such as working with 3D graphics. AGP is independent of the PCI bus and is
intended for exclusive use with graphical-display devices. AGP provides these
performance features:
• Pipelined-memory read and write operations that hide memory
access latency.
• Demultiplexing of address and data on the bus for near-100%
efficiency.
• AC timing for 133MHz data transfer rates, allowing data
throughput of 500 MB per second.
AGP complies with the 66MHz PCI specification.
