2-10 Micron Electronics, Inc.
Micron ClientPro 766Xi/Xe User’s Guide
Installing DIMM Modules
The ClientPro 766Xi/Xe has three, 168-pin DIMM sockets on-board and can
accommodate ECC or non-ECC SDRAM memory from 8MB up to 348MB using
the DIMM combinations on page 2-3.
There are no jumper settings required for the memory size or type, which is
automatically detected by the system BIOS. Gold leaded DlMMs are required
to be used when adding system memory.
DIMM Modules
The memory in this system can be increased up to a maximum of 384MB by
installing DIMMs (dual in-line memory modules). To install DIMMs, first locate
the memory banks on the system board (refer to Figure 2-1). Follow the table
on page 2-3 for the possible installation combinations.
CAUTION: Modules are Electrostatic Sensitive.
Even a small electrostatic discharge could damage the module. A damaged
module might not fail immediately, but over time it will become worse,
possibly causing an "intermittent" problem. Be very careful to handle the
boards ONLY by the edges. DO NOT touch the gold/silver edge-connectors
or any of the components on the board. Leave the module in the antistatic
bag until ready for installation.
1. Switch the computer off. Leave the computer plugged in to the
outlet to provide an electrical ground to discharge static
electricity.
2. Touch the metal case of the power supply or the metal lining
inside the computer case. This will drain the static charge from
your body and will keep the modules from being electrically
damaged.
3. Keep body movement to a minimum as you remove and handle
the modules. Antistatic wrist straps with clip-on ends are
commercially available.
