Features
Details
Power Supply
Wall power adaptor for device
110V / 220V AC to 5V DC
Wall power adaptor for cradle
110V / 220V AC to 12V DC
Peripheral Cables
Main interface cable
Device “Con1” to power, USB, serial, and I/O connectors
Enhanced interface cable
Device “Con2” to serial, I/O, and LAN connectors
J1939 (CANBus) interface
cable
Device “Con3” to CAN connector
Audio interface cable
Device “Con4” to External Audio connectors
Interface Connections
J1708 Adaptor
(requires Enhanced accessory
cable , uses Serial port 2 of CE-
500 device)
RS-232 to J1708 (RS-485) convertor box
RS-422 Adaptor
(requires Enhanced accessory
cable , uses Serial port 2 of CE-
500 device)
RS-232 to RS-422 convertor box
Mechanical Accessories
Mounting arm
- Flexible, multi-directional mounting
- Compatible with cradle or direct device mounting
SD card protective cover
SD card removing protection
SIM card protective cover
SIM card removing protection
Front panel label
Customizable “logo” printout
