MicroNet CE-507 - Enhanced Cradle Connectors

Device Cradle
Device Cradle Connectors
GDUTUG500/01
CE-500 MDT Hardware Guide
78 / 97
C
C
O
O
M
M
2
2
C
C
o
o
n
n
n
n
e
e
c
c
t
t
o
o
r
r
Connector type – Molex Micro-Fit 3.0™ 8 pin plug
Figure 45 – Cradle COM2 Connector Pinout
Table 18 – Cradle COM2 Connector Signal Map
Pin
Signal
Function
Wire Size (AWG)
Required
1
TXD2
Transmit Data (COM2)
28
2
Dallas
One-Wire Interface (DALLAS ID Button Interface)
Port.
28
3
Dig_In2
Digital Input 2
28
4
N/C
Not connected
5
RXD2
Receive Data (COM2)
28
6
DGND
Digital Ground
28
7
An_In1
Analog Input
28
8
AGND
Analog Ground
28
E
E
n
n
h
h
a
a
n
n
c
c
e
e
d
d
c
c
r
r
a
a
d
d
l
l
e
e
C
C
o
o
n
n
n
n
e
e
c
c
t
t
o
o
r
r
s
s
L
L
A
A
N
N
C
C
o
o
n
n
n
n
e
e
c
c
t
t
o
o
r
r
Connector type – RJ45
