Technical and Functional Details
Peripheral Controls
GDUTUG500/01
CE-500 MDT Hardware Guide
36 / 97
A
A
n
n
a
a
l
l
o
o
g
g
I
I
n
n
p
p
u
u
t
t
The platform provides an analog input signal to monitor the voltage range of compatible vehicle sensors,
such as an analog fuel gauge. This signal is connected to the Main Terminal “Con1” connector, which is
located on the bottom panel of the device.
The supported voltage range is from 0V to 30V.
For the disposition map of this signal on Main Terminal “Con1” Connector, see page 38.
In the Fixed-mount mode, this port requires the Enhanced Accessory Cable connection. For the
disposition map of the signals of this port on the Accessory Cable Enhanced Interface cable, see COM2
Connector, on page 65.
For the position of this signal on the Device Cradle, see COM2 Connector, on page 78.
1
1
-
-
W
W
i
i
r
r
e
e
I
I
n
n
t
t
e
e
r
r
f
f
a
a
c
c
e
e
The platform provides the 1-Wire Interface Port connected to the Main Terminal “Con1” connector,
which is located on the bottom panel of the device.
This port provides control, signaling, and power over a single-wire connection. Developers can connect
an optional touch probe accessory and use Dallas ID Memory DS1990A 64 bit ID Buttons for
identification and authorization control. See http://www.maxim-
ic.com/products/ibutton/ibuttons/memoryoverview.cfm
For the disposition map of this signal on Enhanced Terminal “Con2” Connector, see page 39.
In Fixed-mount mode, this port requires the Enhanced Accessory Cable connection. For the disposition
map of the signals of this port on the Accessory Cables Enhanced Interface cable, see COM2 Connector,
on page 65.
For the position of this signal on the Device Cradle, see COM2 Connector, on page 78.
