Depending on the required operating mode of the solution, you can perform electrical installation
using device accessory cables (Fixed-mounted mode) or the device Cradle (Fixed-portable mode).
Both modes provide a similar connectivity type for each specific interface. For example, the Serial
port (COM1) of the device is on the Main accessory cable by a Molex Mini-Automotive 6 pin
receptacle connector type. The same type of connector with the same pinout is located on the rear
panel of the Cradle that provides this interface. This concept is relevant for all interface connectors.
In addition to interfaces that require the standard type of connector (such as USB and Ethernet), all
remaining device signals are located on the cables or Cradle by Molex Micro-Fit 3.0™ Plug connector
types.
C
C
o
o
n
n
n
n
e
e
c
c
t
t
o
o
r
r
s
s
To implement connectivity, use the opposite (Receptacle) type of connector with the correct amount
of pins for each peripheral interface. This is Molex 43025 Series type of connector. Use the Molex
Micro-Fit 3.0™ Crimp Terminal Female for wiring. Ensure the correct wire size (AWG) for each signal
according to Accessory cable requirements or Cradle-Connectors Signal-Map specifications.
