MicroNet CE-507 - Molex 43025 Series Connector

Platform Accessories
GDUTUG500/01
CE-500 MDT Hardware Guide
68 / 97
Figure 35 – IDC Wall mount adapter
NOTE:
External power Charger for the unit must be LPS(Limited power sources).
M
M
o
o
l
l
e
e
x
x
4
4
3
3
0
0
2
2
5
5
S
S
e
e
r
r
i
i
e
e
s
s
C
C
o
o
n
n
n
n
e
e
c
c
t
t
o
o
r
r
A Molex 43025 series connector wall power supply adapter (110V / 220V AC to 12V DC) for connecting
to the CE-500 Main Interface cable DC to DC convertor, or to the Basic and Enhanced Cradle models
(For office usage, available in DTK only).
Figure 36 – Molex 43025 connector Wall mount adapter
NOTE:
External power Charger for the unit must be LPS(Limited power sources).
