CE-500 MDT Hardware Guide
WARNING!
If you use a device that does not include the internal battery option, do not connect the
terminal power to the ignition switch signal. In this case, you prevent uncontrolled power
cut-offs, which may have a detrimental effect on the operating system.
The +Vin signals of the Cradle or Main Accessory cable Power Adaptor Box must be
directly connected to the Vehicle battery. To properly setup power management, you must
connect the Vehicle Ignition Switch signal to the digital input (In1) of the device. For more
information about the power management architecture of the platform, see
Power Management on page 46.
WARNING!
DO NOT USE another battery type!
Risk of explosion if an incorrect battery is used instead of the original battery supplied by
Micronet.
In the Fixed mount mode, the vehicle power connection requires the Main Accessory Cable connection.
For the disposition of the +12V / 24V Vin and Ground signals on the Power–Adaptor-Box of the Main
Accessory Cable, see Power-Adaptor-Box to +Vin Connector, on page 64.
For the position +12V / 24V Vin and Ground signals on the Device Cradle, see +Vin Connector, on page
76.
NOTE:
Connecting the power to the CE-50X device does not enable the device. Only pressing
the Push key or signal rise on the device digital input 1, enables the device from the
power-down state.
If your solution requires device enabling consequently to the power connection, connect
(shorten) the digital Input1 pin with the power-in signal.
I
I
n
n
t
t
e
e
r
r
n
n
a
a
l
l
B
B
a
a
t
t
t
t
e
e
r
r
y
y
(
(
O
O
p
p
t
t
i
i
o
o
n
n
)
)
The platform provides an internal battery pack option to:
Support the device functionality in the Portable mode
Provide power backup in main power source disconnect situations
This option is categorized as a Modular Platform option so it can be included with the device upon
delivery by Micronet as well as to be ordered separately. For more details about the Modular option
architecture, see CE-500 Platform Optional Modules, on page 15.
3000 mAh Lithium-Polymer-based battery is available.
