MicroNet CE-507 - Mounting Arm

Device Installation
Mechanical Installation
GDUTUG500/01
CE-500 MDT Hardware Guide
85 / 97
NOTE:
This guide describes Terminal installation options that use the mounting arm only.
The in-vehicle installation instructions must be provided by a qualified installation
technician.
Pay special attention to mechanical strains when the detachable terminal options are used.
A correct installation location and surface must be chosen as along with installation
materials.
M
M
o
o
u
u
n
n
t
t
i
i
n
n
g
g
A
A
r
r
m
m
The Micronet CE-500 mounting arm is a flexible, rotating, arm-based mounting stand that provides a
wide range of fixed in-cabin positions for maximum comfort and visibility.
Figure 54 – CE-500 Mounting Arm
Table 20 – Mounting Arm Components
Component Picture
Component Name
Mounting Arm stud ball
Arm parts
Screw nut
