MicroNet CE-507 - Page 82

Device Cradle
Device Cradle Connectors
GDUTUG500/01
CE-500 MDT Hardware Guide
82 / 97
Figure 52 – Cradle Speakers Connector
NOTE:
The External Audio interfaces support is an optional feature of the platform. This
interface signals are located on this connector only if the device supports these signals.
Otherwise, the connector pins are not connected and must not be used.
C
C
A
A
N
N
B
B
u
u
s
s
C
C
o
o
n
n
n
n
e
e
c
c
t
t
o
o
r
r
To be documented
This connector is provided by the enhanced Device Cradle model only.
Figure 53 – Cradle CANBus Connector Pinout
NOTE:
The CAN Bus interface is an optional feature of the platform. This interface signals are
located on this connector only if the device supports these signals. Otherwise, the
connector pins are not connected and must not be used.
