NOTE:
One of these inputs (In1) is also used to power on the device from the shutdown state.
For proper power management implementation, the input must be connected to the
vehicle's ignition switch. The platform provides various software control options for this
essential feature. For more details, refer to the Digital I/O and Power Management
sections of the Developers Guide.
Table 2 – Electrical Parameters of Input States
Input State
Typical
Minimum
Maximum
Low
0V
-30V
5V
High
12V-24V
+8V
+30V
D
D
i
i
g
g
i
i
t
t
a
a
l
l
O
O
u
u
t
t
p
p
u
u
t
t
The platform provides a digital output (Open Collector) for external peripherals control. This signal is
connected to the Main Terminal “Con1” connector, which is located on the bottom panel of the device.
Table 3 – Electrical Parameters of Open Collector Output
Parameter
Value
Maximum switchable voltage
+VIN
Maximum switchable current
300mA
For the disposition map of the Digital Input1 and Digital Output signals of this port on Main Terminal
“Con1” Connector, see page 38.
For the disposition map of the Digital Input2 signal of this port on Enhanced Terminal “Con2” Connector,
see page 39.
In the Fixed-mount mode, the Digital Input1 and Digital Output require the Main Accessory Cable and
Digital Input2 requires the Enhanced Accessory Cable connection.
For the disposition map of the Digital Input1 and Digital Output on Power-Adaptor-Box of the Main
Accessory Cable, see Power-Adaptor-Box to +Vin Connector, on page 64.
For the disposition of the Digital Input2 signal on the Accessory Cables Enhanced Interface cable, see
COM2 Connector, on page 65.
For the disposition map of the Digital Input1 and Digital Output on the Device Cradle, see +Vin
Connector, on page 76.
For the disposition of the Digital Input2 signal on the Device Cradle, see COM2 Connector, on page 78.
