Device Cradle
CE-500 Device Basic Cradle Components
GDUTUG500/01
CE-500 MDT Hardware Guide
72 / 97
Figure 38 – CE-500 Device Basic Cradle, Rear Panel
For more information on Basic Cradle rear panel components, see:
 +Vin Connector, on page 76
 LAN connector, on page 78
 COM1 Connector, on page 76
 USB Connector, on page 77
 COM2 Connector ,on page 78
 Mounting Arm screw inserts, on page 85
+Vin Connector
COM1 Connector
USB Connector
Mounting Arm screw inserts
Cables holding handle
Release knob
M_Control1 Connector
COM2 Connector
LAN connector
