Microstep Website http://www.microstep.cc/eng
北京欣斯达特数字科技有限公司 Beijing Flourishing Start Digital Technology Co., Ltd
page: 14
4.4 [DelLin] (delete line): delete all contents in cursor line. Insert a new line, please press
Enter
4.5 [Manage]: manage local disk and U disk.
[1] LoDisk (local disk): controller’s inside disk.
[2] U Disk: U disk.
[3] NewDir (new directory): build a new directory.
[4] DelDir (delete directory): delete a directory.
[5] SeFile (select file): select a file or folder, the option is used with CopyIn (copy in) and
CopyOu (copy out).
[6] DeFile (delete file): delete file, not folder.
[7] CopyIn (copy in): current directory is in U disk, press 5 to choose a or more files or
folders, press 7 to copy them to controller’s disk.
[8] CopyOu (copy out): current directory is in LoDisk (controller’s disk), copy selected
file to U disk; (Note: G button is to select all; X button is to cancel all selection).
4.6 [Proces] (process) change to cutting interface, if not [Open] a program, a tip will appear.
4.7 [Figure]: change between figure and program. Preview the current figure
Note:
[→] enter folder; [←] exit folder.
Chapter 5 Param (parameter) function
[Options instruction of Param (parameter) interface]
[F1]: Exit
[F2] System: important parameters of the controller, don’t change at random
[F3] Speed: set all speed parameters
[F4]: Ctrl (control): control programs and I/O functions
[F5] Craft: flame and plasma
[Switch]: change between flame and plasma
[Save]: save revised parameters
5.1 Enter System interface
5.1.1 Gear numerator/denominator: the ratio is pulse equivalent, unit: μm (1 mm = 1000
μm), numerator < 65535, denominator < 65535.
e.g.: pulse equivalent is 0.008 mm, the electronic gear numerator/denominator = 8/1.
