Group 1 codes and group 2 codes can write in the same program line, and group 1 codes
has higher priority than group 2 codes, in the same program line, group 1 codes firstly run
Group 2 codes are modal codes, if they appear one time, next time they can omit
Group 1 codes and other 2 groups appear in the same program; Group 3 and other 2
groups appear in the same program.
M code
M00: program pause, press [Start] to continue the program
M02: program end
M30: same as M02
M10/M11: gas (acetylene) valve switch, M10 (on), M11 (off)
M12/M13: cutting oxygen valve switch, M12 (on), M13 (off)
M14/M15: torch up switch, M14 (on), M15 (off)
M16/M17: torch down switch, M16 (on), M17 (off)
M24/M25: spare switch, M24 (on), M25 (off)
M20/M21: ignition switch, M20 (0), M21 (off)
M07: pierce cycle (enter M07, can’t back, can move the torch)
M08: close cutting cycle
Flame cutting as below:
M07
1. If gas (acetylene) valve close, then open gas (acetylene) ignition;
2. torch down (torch delay time, M71);
3. open preheat oxygen valve, preheat delay time start, if preheat time is not enough, press
[Pause], preheat delay time automatically increase 150s, if preheat is OK, press [Start], over
preheat delay time, automatically save preheat time as a parameter.
4. torch up (pierce torch up delay time, M72)
5. open cutting oxygen valve (M12), pierce delay time, torch down (M73)
6. open torch height controller (M38), run next program
Plasma cutting as below:
M07
1. torch down (torch delay, M71)
2. if choose “pierce location valid”, torch down till touch low limit position switch, then
stop, torch up, pierce location delay time, then torch stops
Format: G92 X Y
Set current point’s coordinate in workpiece coordinate (cutting coordinate or program
coordinate). The program is only used one time and it’s in the first line.
G code groups
Group Code
1 G90,G91,G40,G41,G42
2 G00,G01,G02,G03
3 G04,G80,G81,G92
