MicroStep CC-S1 User Manual

Microstep Website http://www.microstep.cc/eng
北京欣斯达特数字科技有限公司 Beijing Flourishing Start Digital Technology Co., Ltd
page: 30
Definition 25 pins Instruction
+ limit 1
X/Y+ limit, + limit of two axis serial connection, high is
valid, if don’t use, signal short connect to 24V ground,
if don’t use limit, it can be used as torch collision check
(normally closed)
- limit 14
X/Y- limit, - limit of two axis serial connection, high is valid,
if don’t use, signal short connect to 24V ground
machineX0/
torch up
2
X0 mechanical original point, NPN type proximity switch,
normally open, when reset direction is invalid, it’s outside
torch up, high is valid, if don’t use, signal short circuit
connect to 24V ground
machineY0/
torch down
15
Y0 mechanical original point, NPN type proximity switch,
normally open, when reset direction is invalid, it’s outside
torch down, high is valid, if don’t use, signal short circuit
connect to 24V ground
Arc voltage
check
3
Arc voltage check, low is valid, high before arc voltage
connect
Emergent stop 16
Outside emergent stop, high is valid, if don’t use, signal
short circuit connect to 24V ground
pause 4
Outside pause, high is valid, if don’t use, signal short
circuit connect to 24V ground
location 17 Plasma torch location, lower limit
5
Torch height controller corner signal (torch height
controller auto/man switch) relay normally open contact
output
18 Start arc signal relay normally open contact output
6 COM(OH1/OH2/OH3/OH4) isolation output public port
19 Torch height controller torch（OH4）down normally open
7 Torch height controller torch（OH3）up normally open
20 Torch height controller torch（OH4）down normally closed
8 Torch height controller torch（OH3）up normally closed
M10/M11
Or M38/M39
21
flame: M38 torch height controller M38 on、M39 off
plasma: M10 spare M10 on、M11 off
M20/M21 9
M20 (on), M21 (off), flame: ignition switch, plasma: when
ignition delay time is 0, open all the time (make as change
switch of flame/plasma)
M22/M23 22 spare
M24/M25 10 spare
23 corner（OH1）normally closed contact
11 Cut oxygen（OH2）normally closed contact
24V 24 +24V/1A power
24V 12 +24V/1A power
24V ground 25 24V power ground
24V ground 13 24V power ground
Notice
1. If the controller is used for plasma cutting/welding equipment, shielding wire must be
used to connect the controller and the driver.
2. Input signal external connection is normally closed, invalid is on (low level), valid is off
(high level).
