Midas PRO X

24 PRO X
Navigating The Output Channels
The output channels comprise auxes, matrices and masters.
Master channels
8
6
7
1
2
4
3
5
Master bay channel strip
9
Item Element(s) Description
1
Quick access button —
master channels
Quickly selects the local master channel. Illuminates (blue) when active.
2 To Faders Moves the currently-selected group to the faders below.
3 LCD select button Selects the channel. Has a backlit LCD display (with user-con gurable backlight colour), which shows group name.
4 Mute button Mutes the selected channel.
5 Solo button Solos the selected channel.
6
Channel selection keys
and buttons
The buttons in the channel type section (except the INPUT button) are used with the number keys in the channel select (lower)
section to select a speci c output channel number, assigning it to the control surface (see Fault Finding A Problem Channel.
7 scroll by 1 buttons These left and right scroll buttons scroll through the channels one at a time. Channel selection follows the scrolling.
8 scroll by 24 buttons These left and right scroll buttons scroll through the channels 24 at a time. Channel selection follows the scrolling.
9
Quick access button —
channel strip
Quickly selects the local processing area of the selected channel or channel pair, but doesn’t a ect channel selection.
Illuminates (blue) when active.
