47Quick Start Guide
Input & Output Characteristics
Analogue Input Characteristics
Input Type Load Z Gain Max Level Connector
Surface I/O 10 K -22.5 dB to +65 dB +21 dBu XLR
Talk Mic 600 R +15 dB to +60 dB +6 dBu XLR
Monitor 10 K 0 dB +21 dBu XLR
Analogue Output Characteristics
Output Type Source Z Gain Max Level Connector
Surface I/O 50 R 0 dB +21 dBu XLR
Talk 50 R 0 dB +23 dBu XLR
Monitor 50 R 0 dB +23 dBu XLR
Headphones 10 R +10 dB +21 dBu ¼ inch jack
Digital I/O Characteristics
Type Channels Data Length I/O Description Notes Connector
AES3 2 24 bit input conforms to AES3 -2003 XLR
AES3 2 24 bit output conforms to AES3 -2003 XLR
AES50 24 24 bit bi directional conforms to AES50 -2006 EtherCON XLR
Misc Digital Characteristics
Type I/O Description Notes Connector
Word Clock IN Accepts TTL level, 96 kHz square wave; impedance 75 Ohms BNC
Word Clock OUT Provides a TTL level, 96 kHz square wave BNC
AES Sync IN Accepts a digital audio signal conforming to AES3 -2003 at 96 kHz XLR
AES Sync OUT Provides a grade II reference signal conforming to AES3 – 2003 at 96 kHz XLR
